FormEngine Core provides a powerful, flexible validation system built on the robust Zod validation library. This guide will help you understand how to implement validation in your forms, from simple required fields to complex conditional validation logic.

What is Validation?

Validation is the process of ensuring that data entered by users meets your application’s requirements. It’s like a quality control system for your forms that:

Prevents invalid data from being submitted
Provides immediate feedback to users
Reduces errors and improves data quality
Enhances user experience by guiding correct input

FormEngine Core’s validation system is type-safe, extensible, and integrates seamlessly with both JSON form definitions and TypeScript APIs.

How Validation Works

Validation Flow

When the user interacts with a form field (component), FormEngine Core performs the following actions:

Checks whether automatic validation is enabled for this field (enabled by default).
If automatic validation is disabled for a field, then validation is not performed.
Executes all validators specified for this field in the order of their sequence in the JSON array.
If at least one of the validators returns a validation error, the validation error is localized (optionally) and displayed to the user.

Field Validation

Field validation is the most common type of validation - applying rules to individual form fields.

Adding Validation to Fields

You can add validation to fields using JSON configuration.

JSON Configuration

In JSON form definitions, add validation rules to the schema.validations array:

{
  "key": "email",
  "type": "MuiTextField",
  "props": {
    "label": {
      "value": "Email Address"
    },
    "helperText": {
      "value": "Start typing"
    }
  },
  "schema": {
    "validations": [
      {
        "key": "required",
        "args": {
          "message": "Email is required"
        }
      },
      {
        "key": "email",
        "args": {
          "message": "Please enter a valid email address"
        }
      },
      {
        "key": "max",
        "args": {
          "limit": 20,
          "message": "Email cannot exceed 20 characters"
        }
      }
    ]
  }
}

In the example above, we have a description of a single component of type MuiTextField. MuiTextField is a component that has a property bound to data of type string. There are three validators for this component: required, email, and max. When the user enters data, validation occurs. FormEngine Core will find three validators with keys required, email, max associated with the string type. It will call these validators and display an error.

Live example

live

function App() {
  const form = {
    "errorType": "MuiErrorWrapper",
    "form": {
      "key": "Screen",
      "type": "Screen",
      "children": [
        {
          "key": "email",
          "type": "MuiTextField",
          "props": {
            "label": {
              "value": "Email Address"
            },
            "helperText": {
              "value": "Start typing"
            }
          },
          "schema": {
            "validations": [
              {
                "key": "required",
                "args": {
                  "message": "Email is required"
                }
              },
              {
                "key": "email",
                "args": {
                  "message": "Please enter a valid email address"
                }
              },
              {
                "key": "max",
                "args": {
                  "limit": 20,
                  "message": "Email cannot exceed 20 characters"
                }
              }
            ]
          }
        }
      ]
    }
  }

  const getForm = useCallback(() => JSON.stringify(form), [form])

  return <FormViewer
    view={muiView}
    getForm={getForm}
  />
}

Built-in Validators Based on Zod

FormEngine Core includes a comprehensive set of validators powered by Zod. These validators are organized by data type.

String Validators

String validators work with text inputs, textareas, and any component that accepts text values. Validators can accept arguments. A special argument for built-in validators is message, the error text that will be returned to the user. The message argument is optional.

Validator	Description	Example JSON
`required`	Field must not be empty	`{"key": "required", "args": {"message": "This field is required"}}`
`nonEmpty`	Field must not be empty (alias for required)	`{"key": "nonEmpty", "args": {"message": "Cannot be empty"}}`
`min`	Minimum length	`{"key": "min", "args": {"limit": 3, "message": "Must be at least 3 characters"}}`
`max`	Maximum length	`{"key": "max", "args": {"limit": 100, "message": "Cannot exceed 100 characters"}}`
`length`	Exact length	`{"key": "length", "args": {"length": 10, "message": "Must be exactly 10 characters"}}`
`email`	Valid email format	`{"key": "email", "args": {"message": "Invalid email address"}}`
`url`	Valid URL format	`{"key": "url", "args": {"message": "Invalid URL"}}`
`uuid`	Valid UUID format	`{"key": "uuid", "args": {"message": "Invalid UUID"}}`
`ip`	Valid IP address (IPv4 or IPv6)	`{"key": "ip", "args": {"message": "Invalid IP address"}}`
`datetime`	ISO datetime format	`{"key": "datetime", "args": {"message": "Invalid datetime format"}}`
`regex`	Custom regular expression	`{"key": "regex", "args": {"regex": "^[A-Z][a-z]+$", "message": "Must start with capital letter"}}`
`includes`	Contains substring	`{"key": "includes", "args": {"value": "example", "message": "Must contain 'example'"}}`
`startsWith`	Starts with substring	`{"key": "startsWith", "args": {"value": "Mr.", "message": "Must start with 'Mr.'"}}`
`endsWith`	Ends with substring	`{"key": "endsWith", "args": {"value": ".com", "message": "Must end with '.com'"}}`

Number Validators

Number validators work with numeric inputs and selectors.

Validator	Description	Example JSON
`required`	Field must contain a number	`{"key": "required", "args": {"message": "This field is required"}}`
`min`	Minimum value	`{"key": "min", "args": {"limit": 18, "message": "Must be at least 18"}}`
`max`	Maximum value	`{"key": "max", "args": {"limit": 120, "message": "Cannot exceed 120"}}`
`lessThan`	Less than value	`{"key": "lessThan", "args": {"value": 100, "message": "Must be less than 100"}}`
`moreThan`	Greater than value	`{"key": "moreThan", "args": {"value": 0, "message": "Must be greater than 0"}}`
`integer`	Must be an integer	`{"key": "integer", "args": {"message": "Must be a whole number"}}`
`multipleOf`	Multiple of value	`{"key": "multipleOf", "args": {"value": 5, "message": "Must be a multiple of 5"}}`

Date Validators

Date validators work with date pickers and date inputs.

Validator	Description	Example JSON
`required`	Field must contain a date	`{"key": "required", "args": {"message": "Date is required"}}`
`min`	Minimum date	`{"key": "min", "args": {"value": "2024-01-01", "message": "Cannot be before 2024"}}`
`max`	Maximum date	`{"key": "max", "args": {"value": "2024-12-31", "message": "Cannot be after 2024"}}`

Array Validators

Array validators work with multi-selects, checkboxes, and repeaters.

Validator	Description	Example JSON
`required`	Array must not be empty	`{"key": "required", "args": {"message": "At least one item is required"}}`
`nonEmpty`	Array must not be empty	`{"key": "nonEmpty", "args": {"message": "Cannot be empty"}}`
`min`	Minimum array length	`{"key": "min", "args": {"limit": 1, "message": "Select at least one item"}}`
`max`	Maximum array length	`{"key": "max", "args": {"limit": 5, "message": "Cannot select more than 5 items"}}`
`length`	Exact array length	`{"key": "length", "args": {"length": 3, "message": "Must select exactly 3 items"}}`

Boolean Validators

Boolean validators work with checkboxes and switches.

Validator	Description	Example JSON
`required`	Must be true (checked)	`{"key": "required", "message": "This must be checked"}`
`truthy`	Must be true (checked)	`{"key": "truthy", "message": "This must be checked"}`
`falsy`	Must be true (unchecked)	`{"key": "falsy", "message": "This must be unchecked"}`

Time Validators

Time validators work with components whose data is time.

Validator	Description	Example JSON
`required`	Field must contain a time	`{"key": "required", "message": "Time is required"}`

Form Validation

Form validation allows you to validate the entire form or groups of fields together.

Form-Level Validation

You can validate the entire form using the validate action:

{
  "type": "MuiButton",
  "key": "submitButton",
  "props": {
    "children": {
      "value": "Submit"
    }
  },
  "events": {
    "onClick": [
      {
        "name": "validate",
        "type": "common",
        "args": {
          "failOnError": true
        }
      },
      {
        "name": "onSubmit",
        "type": "custom"
      }
    ]
  }
}

Live example

live

function App() {
  const form = {
    "errorType": "MuiErrorWrapper",
    "form": {
      "key": "Screen",
      "type": "Screen",
      "children": [
        {
          "key": "email",
          "type": "MuiTextField",
          "props": {
            "label": {
              "value": "Email Address"
            },
            "helperText": {
              "value": "Start typing"
            }
          },
          "schema": {
            "validations": [
              {
                "key": "email",
                "args": {
                  "message": "Please enter a valid email address"
                }
              }
            ]
          }
        },
        {
          "type": "MuiButton",
          "key": "submitButton",
          "props": {
            "children": {
              "value": "Submit"
            }
          },
          "events": {
            "onClick": [
              {
                "name": "validate",
                "type": "common",
                "args": {
                  "failOnError": true
                }
              },
              {
                "name": "onSubmit",
                "type": "custom"
              }
            ]
          }
        }
      ]
    }
  }

  const getForm = useCallback(() => JSON.stringify(form), [form])

  const actions = {
    onSubmit: () => {
      alert('Form validation is successful!')
    }
  }

  return <FormViewer
    view={muiView}
    getForm={getForm}
    actions={actions}
  />
}

The validate action with failOnError: true will prevent the onSubmit action from running if any validation errors exist.

Conditional Validation

Conditional validation allows you to apply validation rules only when certain conditions are met.

Using validateWhen Property

The validateWhen property accepts a JavaScript expression that determines when the validation should run. An expression is essentially a JavaScript statement that returns true or false. As input, it receives the form parameter with all the information from the form.

{
  "key": "phone",
  "type": "MuiTextField",
  "props": {
    "label": {
      "value": "Phone"
    },
    "helperText": {
      "value": "This field must be filled in only if the phone is selected as the contact method"
    }
  },
  "schema": {
    "validations": [
      {
        "key": "regex",
        "args": {
          "regex": "^[\\+\\d\\s\\-\\(\\)]{10,15}$",
          "message": "Invalid phone number format"
        },
        "validateWhen": {
          "value": "form.data.contactMethod === 'phone'"
        }
      }
    ]
  }
}

Live example

live

function App() {
  const form = {
    "errorType": "MuiErrorWrapper",
    "form": {
      "key": "Screen",
      "type": "Screen",
      "children": [
        {
          "key": "contactMethod",
          "type": "MuiSelect",
          "props": {
            "items": {
              "value": [
                {
                  "value": "email",
                  "label": "Email"
                },
                {
                  "value": "phone",
                  "label": "Phone"
                }
              ]
            },
            "label": {
              "value": "Contact method"
            }
          },
          "schema": {
            "validations": [
              {
                "key": "required"
              }
            ]
          }
        },
        {
          "key": "phone",
          "type": "MuiTextField",
          "props": {
            "label": {
              "value": "Phone"
            },
            "helperText": {
              "value": "This field must be filled in only if the phone is selected as the contact method"
            }
          },
          "schema": {
            "validations": [
              {
                "key": "regex",
                "args": {
                  "regex": "^[\\+\\d\\s\\-\\(\\)]{10,15}$",
                  "message": "Invalid phone number format"
                },
                "validateWhen": {
                  "value": "form.data.contactMethod === 'phone'"
                }
              }
            ]
          }
        },
        {
          "key": "submit",
          "type": "MuiButton",
          "props": {
            "children": {
              "value": "Validate"
            }
          },
          "events": {
            "onClick": [
              {
                "name": "validate",
                "type": "common"
              }
            ]
          }
        }
      ]
    }
  }

  const getForm = useCallback(() => JSON.stringify(form), [form])

  return <FormViewer
    view={muiView}
    getForm={getForm}
  />
}

Complex Conditional Validation

You can create complex validation logic that depends on multiple fields:

{
  "key": "businessAddress",
  "type": "MuiTextField",
  "props": {
    "label": {
      "value": "Business address"
    }
  },
  "schema": {
    "validations": [
      {
        "key": "required",
        "args": {
          "message": "Business address is required for corporate accounts"
        },
        "validateWhen": {
          "value": "form.data.accountType === 'corporate' && form.data.hasPhysicalLocation === true"
        }
      },
      {
        "key": "min",
        "args": {
          "limit": 10,
          "message": "Address must be at least 10 characters"
        },
        "validateWhen": {
          "value": "form.data.accountType === 'corporate' && form.data.businessAddress && form.data.businessAddress.length > 0"
        }
      }
    ]
  }
}

Live example

live

function App() {
  const form = {
    "errorType": "MuiErrorWrapper",
    "form": {
      "key": "Screen",
      "type": "Screen",
      "children": [
        {
          "key": "accountType",
          "type": "MuiSelect",
          "props": {
            "label": {
              "value": "Account type"
            },
            "items": {
              "value": [
                {
                  "value": "corporate",
                  "label": "Corporate"
                },
                {
                  "value": "personal",
                  "label": "Personal"
                }
              ]
            },
            "value": {
              "value": "corporate"
            }
          }
        },
        {
          "key": "hasPhysicalLocation",
          "type": "MuiFormControlLabel",
          "props": {
            "control": {
              "value": "Switch"
            },
            "label": {
              "value": "Has physical location"
            }
          }
        },
        {
          "key": "businessAddress",
          "type": "MuiTextField",
          "props": {
            "label": {
              "value": "Business address"
            }
          },
          "schema": {
            "validations": [
              {
                "key": "required",
                "args": {
                  "message": "Business address is required for corporate accounts"
                },
                "validateWhen": {
                  "value": "form.data.accountType === 'corporate' && form.data.hasPhysicalLocation === true"
                }
              },
              {
                "key": "min",
                "args": {
                  "limit": 10,
                  "message": "Address must be at least 10 characters"
                },
                "validateWhen": {
                  "value": "form.data.accountType === 'corporate' && form.data.businessAddress && form.data.businessAddress.length > 0"
                }
              }
            ]
          }
        },
        {
          "key": "validate",
          "type": "MuiButton",
          "props": {
            "children": {
              "value": "Validate"
            }
          },
          "events": {
            "onClick": [
              {
                "name": "validate",
                "type": "common"
              }
            ]
          }
        }
      ]
    }
  }

  const getForm = useCallback(() => JSON.stringify(form), [form])

  return <FormViewer
    view={muiView}
    getForm={getForm}
  />
}

Code Validation

Code validation allows you to write custom validation logic using JavaScript code. This is the most flexible validation option. The function body of this validator is stored in JSON.

Code Validation Parameters

The code validator has access to these parameters:

value: The current field value
form: The complete form data object

The function should return true if validation passes, or false if validation fails.

Basic Code Validation

For example, we want to add a date validator so that the value in the field is greater than the current date. Here is a sample code:

/**
 * @param {string} value the validated value.
 * @param {IFormData} form the form.
 * @return {boolean} the validation result.
 */
async (value, form) => {
  if (!value) return true;

  const today = new Date();
  today.setHours(0, 0, 0, 0);
  const selected = new Date(value);
  selected.setHours(0, 0, 0, 0);

  if (selected < today) {
    return false;
  }

  return true;
}

Add a code validator with custom JavaScript logic:

{
  "key": "checkInDate",
  "type": "RsDatePicker",
  "props": {
    "label": {
      "value": "Check-in date"
    }
  },
  "schema": {
    "validations": [
      {
        "key": "required",
        "args": {
          "message": "Check-in date is required"
        }
      },
      {
        "key": "code",
        "args": {
          "message": "Check-in date cannot be in the past",
          "code": "    if (!value) return true;\n\n    const today = new Date();\n    today.setHours(0, 0, 0, 0);\n    const selected = new Date(value);\n    selected.setHours(0, 0, 0, 0);\n\n    if (selected < today) {\n        return false;\n    }\n\n    return true;"
        }
      }
    ]
  }
}

Live example

live

function App() {
  const form = {
    "errorType": "RsErrorMessage",
    "form": {
      "key": "Screen",
      "type": "Screen",
      "children": [
        {
          "key": "checkInDate",
          "type": "RsDatePicker",
          "props": {
            "label": {
              "value": "Check-in date"
            }
          },
          "schema": {
            "validations": [
              {
                "key": "required",
                "args": {
                  "message": "Check-in date is required"
                }
              },
              {
                "key": "code",
                "args": {
                  "message": "Check-in date cannot be in the past",
                  "code": "    if (!value) return true;\n\n    const today = new Date();\n    today.setHours(0, 0, 0, 0);\n    const selected = new Date(value);\n    selected.setHours(0, 0, 0, 0);\n\n    if (selected < today) {\n        return false;\n    }\n\n    return true;"
                }
              }
            ]
          }
        },
        {
          "key": "validate",
          "type": "RsButton",
          "props": {
            "children": {
              "value": "Validate"
            }
          },
          "events": {
            "onClick": [
              {
                "name": "validate",
                "type": "common"
              }
            ]
          }
        }
      ]
    }
  }

  const getForm = useCallback(() => JSON.stringify(form), [form])

  return <FormViewer
    view={rSuiteView}
    getForm={getForm}
  />
}

Cross-Field Validation with Code

Validate relationships between multiple fields:

/**
 * @param {string} value the validated value.
 * @param {IFormData} form the form.
 * @return {boolean} the validation result.
 */
async (value, form) => {
  if (!value) return true;

  const checkIn = new Date(form.data.checkInDate);
  checkIn.setHours(0, 0, 0, 0);
  const checkOut = new Date(value);
  checkOut.setHours(0, 0, 0, 0);

  return checkOut > checkIn
}

/**
 * @param {string} value the validated value.
 * @param {IFormData} form the form.
 * @return {boolean} the validation result.
 */
async (value, form) => {
  if (!value) return true;

  const checkIn = new Date(form.data.checkInDate);
  checkIn.setHours(0, 0, 0, 0);
  const checkOut = new Date(value);
  checkOut.setHours(0, 0, 0, 0);

  // Maximum 30-day stay
  const maxStay = new Date(checkIn);
  maxStay.setDate(maxStay.getDate() + 30);

  return checkOut <= maxStay
}

{
  "key": "checkOutDate",
  "type": "RsDatePicker",
  "props": {
    "label": {
      "value": "Check-out date"
    }
  },
  "schema": {
    "validations": [
      {
        "key": "required",
        "args": {
          "message": "Check-out date is required"
        }
      },
      {
        "key": "code",
        "args": {
          "message": "Check-out date must be after check-in date",
          "code": "    if (!value) return true;\n\n    const checkIn = new Date(form.data.checkInDate);\n    checkIn.setHours(0, 0, 0, 0);\n    const checkOut = new Date(value);\n    checkOut.setHours(0, 0, 0, 0);\n\n    return checkOut > checkIn"
        }
      },
      {
        "key": "code",
        "args": {
          "message": "Maximum stay is 30 days",
          "code": "    if (!value) return true;\n\n    const checkIn = new Date(form.data['checkInDate']);\n    checkIn.setHours(0, 0, 0, 0);\n    const checkOut = new Date(value);\n    checkOut.setHours(0, 0, 0, 0);\n\n    // Maximum 30-day stay\n    const maxStay = new Date(checkIn);\n    maxStay.setDate(maxStay.getDate() + 30);\n\n    return checkOut <= maxStay"
        }
      }
    ]
  }
}

Live example

live

function App() {
  const form = {
    "errorType": "RsErrorMessage",
    "form": {
      "key": "Screen",
      "type": "Screen",
      "children": [
        {
          "key": "checkInDate",
          "type": "RsDatePicker",
          "props": {
            "label": {
              "value": "Check-in date"
            }
          },
          "schema": {
            "validations": [
              {
                "key": "required",
                "args": {
                  "message": "Check-in date is required"
                }
              },
              {
                "key": "code",
                "args": {
                  "message": "Invalid check-in date",
                  "code": "    if (!value) return true;\n\n    const today = new Date();\n    today.setHours(0, 0, 0, 0);\n    const selected = new Date(value);\n    selected.setHours(0, 0, 0, 0);\n\n    if (selected < today) {\n        return false;\n    }\n\n    return true;"
                }
              }
            ]
          }
        },
        {
          "key": "checkOutDate",
          "type": "RsDatePicker",
          "props": {
            "label": {
              "value": "Check-out date"
            }
          },
          "schema": {
            "validations": [
              {
                "key": "required",
                "args": {
                  "message": "Check-out date is required"
                }
              },
              {
                "key": "code",
                "args": {
                  "message": "Check-out date must be after check-in date",
                  "code": "    if (!value) return true;\n\n    const checkIn = new Date(form.data.checkInDate);\n    checkIn.setHours(0, 0, 0, 0);\n    const checkOut = new Date(value);\n    checkOut.setHours(0, 0, 0, 0);\n\n    return checkOut > checkIn"
                }
              },
              {
                "key": "code",
                "args": {
                  "message": "Maximum stay is 30 days",
                  "code": "    if (!value) return true;\n\n    const checkIn = new Date(form.data.checkInDate);\n    checkIn.setHours(0, 0, 0, 0);\n    const checkOut = new Date(value);\n    checkOut.setHours(0, 0, 0, 0);\n\n    // Maximum 30-day stay\n    const maxStay = new Date(checkIn);\n    maxStay.setDate(maxStay.getDate() + 30);\n\n    return checkOut <= maxStay"
                }
              }
            ]
          }
        },
        {
          "key": "validate",
          "type": "RsButton",
          "props": {
            "children": {
              "value": "Validate"
            }
          },
          "events": {
            "onClick": [
              {
                "name": "validate",
                "type": "common"
              }
            ]
          }
        }
      ]
    }
  }

  const getForm = useCallback(() => JSON.stringify(form), [form])

  return <FormViewer
    view={rSuiteView}
    getForm={getForm}
  />
}

Custom Validation

Custom validation allows you to create reusable validators that can be registered and used across your application. Custom validators are passed to the FormViewer component’s props via prop validators, and custom validators are connected to form components as well as embedded validators via JSON forms, but with the addition of the custom type.

Registering Custom Validators

const validators: FormViewerProps['validators'] = {
  string: {
    strongPassword: {
      validate: (value, store, args, formData) => {
        if (!value) return false

        const hasUpperCase = /[A-Z]/.test(value)
        if (!hasUpperCase) return 'Must contain at least one uppercase letter'

        const hasLowerCase = /[a-z]/.test(value)
        if (!hasLowerCase) return 'Must contain at least one lowercase letter'

        const hasNumbers = /\d/.test(value)
        if (!hasNumbers) return 'Must contain at least one number'

        const hasSpecialChars = /[!@#$%^&*(),.?":{}|<>]/.test(value)
        if (!hasSpecialChars) return 'Must contain at least one special character'

        const isLongEnough = value.length >= 8
        if (!isLongEnough) return 'Must be at least 8 characters long'

        return true
      }
    }
  }
}

export const App = () => {

  const getForm = useCallback(() => {
    // your form here
    return JSON.stringify({
      form: {
        key: 'Screen',
        type: 'Screen'
      }
    })
  }, [])

  return <FormViewer view={view}
                     getForm={getForm}
                     validators={validators}
  />
}

Using Custom Validators

Use registered custom validators in your form JSON:

{
  "key": "password",
  "type": "MuiTextField",
  "props": {
    "label": {
      "value": "Password"
    }
  },
  "schema": {
    "validations": [
      {
        "key": "required"
      },
      {
        "key": "strongPassword",
        "type": "custom"
      }
    ]
  }
}

Live example

live

function App() {
  const validators = {
    string: {
      strongPassword: {
        validate: (value, store, args, formData) => {
          if (!value) return false

          const hasUpperCase = /[A-Z]/.test(value)
          if (!hasUpperCase) return 'Must contain at least one uppercase letter'

          const hasLowerCase = /[a-z]/.test(value)
          if (!hasLowerCase) return 'Must contain at least one lowercase letter'

          const hasNumbers = /\d/.test(value)
          if (!hasNumbers) return 'Must contain at least one number'

          const hasSpecialChars = /[!@#$%^&*(),.?":{}|<>]/.test(value)
          if (!hasSpecialChars) return 'Must contain at least one special character'

          const isLongEnough = value.length >= 8
          if (!isLongEnough) return 'Must be at least 8 characters long'

          return true
        }
      }
    }
  }

  const form = {
    "errorType": "MuiErrorWrapper",
    "form": {
      "key": "Screen",
      "type": "Screen",
      "children": [
        {
          "key": "password",
          "type": "MuiTextField",
          "props": {
            "label": {
              "value": "Password"
            }
          },
          "schema": {
            "validations": [
              {
                "key": "required"
              },
              {
                "key": "strongPassword",
                "type": "custom"
              }
            ]
          }
        },
        {
          "key": "submit",
          "type": "MuiButton",
          "props": {
            "children": {
              "value": "Validate"
            }
          },
          "events": {
            "onClick": [
              {
                "name": "validate",
                "type": "common"
              }
            ]
          }
        }
      ]
    }
  }

  const getForm = useCallback(() => JSON.stringify(form), [form])

  return <FormViewer
    view={muiView}
    getForm={getForm}
    validators={validators}
  />
}

Custom Validator with Parameters

Create parameterized custom validators:

// Register validator with parameters
const validators: FormViewerProps['validators'] = {
  string: {
    matchesField: {
      validate: (value, store, args, formData) => {
        if (!value || !args?.fieldName) return false

        const fieldName = args.fieldName as string
        const otherValue = formData?.data[fieldName]

        if (value !== otherValue) {
          return (args?.message as string) || `Must match ${fieldName}`
        }

        return true
      },
      params: [
        {
          key: 'fieldName',
          type: 'string',
          required: true
        },
        {
          key: 'message',
          type: 'string',
          required: true,
          default: 'Fields do not match'
        }
      ]
    }
  }
}

{
  "key": "confirmPassword",
  "type": "MuiTextField",
  "props": {
    "label": {
      "value": "Confirm password"
    }
  },
  "schema": {
    "validations": [
      {
        "key": "required",
        "message": "Please confirm your password"
      },
      {
        "key": "matchesField",
        "type": "custom",
        "args": {
          "fieldName": "password",
          "message": "Passwords do not match"
        }
      }
    ]
  }
}

Live example

live

function App() {
  const validators = {
    string: {
      matchesField: {
        validate: (value, store, args, formData) => {
          if (!value || !args?.fieldName) return false

          const fieldName = args.fieldName
          const otherValue = formData?.data[fieldName]

          if (value !== otherValue) {
            return args?.message || `Must match ${fieldName}`
          }

          return true
        },
        params: [
          {
            key: 'fieldName',
            type: 'string',
            required: true
          },
          {
            key: 'message',
            type: 'string',
            required: true,
            default: 'Fields do not match'
          }
        ]
      }
    }
  }

  const form = {
    "errorType": "MuiErrorWrapper",
    "form": {
      "key": "Screen",
      "type": "Screen",
      "children": [
        {
          "key": "password",
          "type": "MuiTextField",
          "props": {
            "label": {
              "value": "Password"
            }
          },
          "schema": {
            "validations": [
              {
                "key": "required"
              }
            ]
          }
        },
        {
          "key": "confirmPassword",
          "type": "MuiTextField",
          "props": {
            "label": {
              "value": "Confirm password"
            }
          },
          "schema": {
            "validations": [
              {
                "key": "required",
                "message": "Please confirm your password"
              },
              {
                "key": "matchesField",
                "type": "custom",
                "args": {
                  "fieldName": "password",
                  "message": "Passwords do not match"
                }
              }
            ]
          }
        },
        {
          "key": "submit",
          "type": "MuiButton",
          "props": {
            "children": {
              "value": "Validate"
            }
          },
          "events": {
            "onClick": [
              {
                "name": "validate",
                "type": "common"
              }
            ]
          }
        }
      ]
    }
  }

  const getForm = useCallback(() => JSON.stringify(form), [form])

  return <FormViewer
    view={muiView}
    getForm={getForm}
    validators={validators}
  />
}

Automatic Validation

How Automatic Validation Works

By default, FormEngine Core performs automatic field validation when the value of this field changes.

Disabling Automatic Validation

You can disable automatic validation for specific fields using the autoValidate property:

{
  "key": "searchQuery",
  "type": "MuiTextField",
  "props": {
    "label": {
      "value": "Search"
    }
  },
  "schema": {
    "validations": [
      {
        "key": "required"
      },
      {
        "key": "min",
        "args": {
          "limit": 3,
          "message": "Search query must be at least 3 characters"
        }
      }
    ],
    "autoValidate": false
  }
}

With autoValidate: false, the field will only be validated when explicitly triggered (e.g., during validate action).

Validation Error Display

Default Error Display

FormEngine Core automatically displays validation errors next to the corresponding field. To display errors in the form, FormEngine Core uses the component specified in the JSON file of the form in the errorType field. An example for MUI components:

{
  "errorType": "MuiErrorWrapper",
  "form": {
    "key": "Screen",
    "type": "Screen"
  }
}

Custom Error Display

You can configure the error display by specifying the errorProps field in JSON. This field describes the properties that will be passed to the component specified in the errorType field.

{
  "errorProps": {
    "placement": {
      "value": "bottomEnd"
    }
  },
  "errorType": "RsErrorMessage",
  "form": {
    "key": "Screen",
    "type": "Screen"
  }
}

How to add your own component to display the error

Showing All Validation Errors

By default, FormEngine Core displays the first validation error for a component, even if the component has multiple validators specified. You can configure FormViewer so that it displays all validation errors for the component at once. To do this, set the value of the showAllValidationErrors property to true.

<FormViewer
  view={muiView}
  getForm={getForm}
  showAllValidationErrors={true}
/>

Live example

live

function App() {
  const form = {
    "errorType": "MuiErrorWrapper",
    "form": {
      "key": "Screen",
      "type": "Screen",
      "children": [
        {
          "key": "url",
          "type": "MuiTextField",
          "props": {
            "label": {
              "value": "URL"
            },
            "helperText": {
              "value": "Example: https://google.com"
            }
          },
          "schema": {
            "validations": [
              {
                "key": "required"
              },
              {
                "key": "url"
              }
            ]
          }
        },
        {
          "key": "submit",
          "type": "MuiButton",
          "props": {
            "children": {
              "value": "Validate"
            }
          },
          "events": {
            "onClick": [
              {
                "name": "validate",
                "type": "common"
              }
            ]
          }
        }
      ]
    }
  }

  const getForm = useCallback(() => JSON.stringify(form), [form])

  return <FormViewer
    view={muiView}
    getForm={getForm}
    showAllValidationErrors={true}
  />
}

Advanced Form Validation

Advanced form validation allows you to validate the entire form data with custom logic that can check relationships between multiple fields, perform complex business rules, and validate data consistency across the entire form.

Form Validator in JSON (formValidator)

You can define a form-level validator directly in the JSON form definition using the formValidator field. This validator runs JavaScript code that has access to all form data and returns validation errors for any field. The form validation function accepts the formData argument as input, which is an object with form data. Below is an example of such a function (only the function body is stored in JSON):

/**
 * @param {Record<string, unknown>} formData the form data.
 * @returns {Record<string, string> | undefined} the validation result.
 */
async (formData) => {
  const result = {};
  if (!formData.email || !formData.email.includes('@')) {
    result.email = 'Invalid email format';
  }
  if (!formData.password || formData.password.length < 8) {
    result.password = 'Password must be at least 8 characters';
  }
  if (formData.confirmPassword !== formData.password) {
    result.confirmPassword = 'Passwords do not match';
  }
  return result;
}

Basic Example

{
"formValidator": "  const result = {};\n  if (!formData.email || !formData.email.includes('@')) {\n
result.email = 'Invalid email format';\n  }\n  if (!formData.password || formData.password.length <
8) {\n    result.password = 'Password must be at least 8 characters';\n  }\n  if
(formData.confirmPassword !== formData.password) {\n    result.confirmPassword = 'Passwords do not
match';\n  }\n  return result;",
  "tooltipType": "MuiTooltip",
  "errorType": "MuiErrorWrapper",
  "form": {
    "key": "Screen",
    "type": "Screen",
    "children": [
      {
        "key": "email",
        "type": "MuiTextField",
        "props": {
          "label": {
            "value": "Email"
          }
        }
      },
      {
        "key": "password",
        "type": "MuiTextField",
        "props": {
          "label": {
            "value": "Password"
          },
          "type": {
            "value": "password"
          }
        }
      },
      {
        "key": "confirmPassword",
        "type": "MuiTextField",
        "props": {
          "label": {
            "value": "Confirm Password"
          },
          "type": {
            "value": "password"
          }
        }
      },
      {
        "key": "submit",
        "type": "MuiButton",
        "props": {
          "children": {
            "value": "Validate"
          }
        },
        "events": {
          "onClick": [
            {
              "name": "validate",
              "type": "common"
            }
          ]
        }
      }
    ]
  }
}

Live example

live

function App() {
  const form = {
    "formValidator": "  const result = {};\n  if (!formData.email || !formData.email.includes('@')) {\n    result.email = 'Invalid email format';\n  }\n  if (!formData.password || formData.password.length < 8) {\n    result.password = 'Password must be at least 8 characters';\n  }\n  if (formData.confirmPassword !== formData.password) {\n    result.confirmPassword = 'Passwords do not match';\n  }\n  return result;",
    "tooltipType": "MuiTooltip",
    "errorType": "MuiErrorWrapper",
    "form": {
      "key": "Screen",
      "type": "Screen",
      "children": [
        {
          "key": "email",
          "type": "MuiTextField",
          "props": {
            "label": {
              "value": "Email"
            }
          }
        },
        {
          "key": "password",
          "type": "MuiTextField",
          "props": {
            "label": {
              "value": "Password"
            },
            "type": {
              "value": "password"
            }
          }
        },
        {
          "key": "confirmPassword",
          "type": "MuiTextField",
          "props": {
            "label": {
              "value": "Confirm Password"
            },
            "type": {
              "value": "password"
            }
          }
        },
        {
          "key": "submit",
          "type": "MuiButton",
          "props": {
            "children": {
              "value": "Validate"
            }
          },
          "events": {
            "onClick": [
              {
                "name": "validate",
                "type": "common"
              }
            ]
          }
        }
      ]
    }
  }

  const getForm = useCallback(() => JSON.stringify(form), [form])

  return <FormViewer
    view={muiView}
    getForm={getForm}
  />
}

Form Validator Function Signature

The formValidator code should be a JavaScript function body that:

Receives a formData parameter containing all form field values
Returns an object where:

Keys are field names
Values are error messages for those fields

Returns an empty object {} or undefined if validation passes

// Example formValidator function
async function validateForm(formData) {
  const errors = {};

  // Validate email
  if (!formData.email || !formData.email.includes('@')) {
    result.email = 'Invalid email format';
  }

  // Validate password strength
  if (!formData.password || formData.password.length < 8) {
    result.password = 'Password must be at least 8 characters';
  }

  // Validate password confirmation
  if (formData.confirmPassword !== formData.password) {
    errors.confirmPassword = 'Passwords do not match';
  }

  // Complex business rule: age must be 18+ for registration
  if (formData.age && formData.age < 18) {
    errors.age = 'You must be at least 18 years old';
  }

  // Return errors object (empty if validation passes)
  return Object.keys(errors).length > 0 ? errors : undefined;
}

External Form Validators via FormViewer (formValidators)

For more complex validation scenarios or when you need to reuse validation logic across multiple forms, you can provide external form validators through the formValidators property of the FormViewer component.

Registering External Form Validators

const formJson = {
  // your form
}

// Define external form validators
const validators: FormValidator[] = [
  async (formData) => {
    const errors: Record<string, string> = {}

    if (!formData.username) {
      errors.username = 'Please provide the username'
    }

    // Check if username is already taken (simulate async check)
    if (formData.username === 'admin') {
      errors.username = 'Username "admin" is reserved'
    }

    if (!formData.password) {
      errors.password = 'Please provide the password'
    }

    // Validate password strength
    if (formData.password) {
      const hasUpperCase = /[A-Z]/.test(formData.password as string)
      const hasLowerCase = /[a-z]/.test(formData.password as string)
      const hasNumbers = /\d/.test(formData.password as string)

      if (!hasUpperCase) errors.password = 'Must contain uppercase letter'
      if (!hasLowerCase) errors.password = 'Must contain lowercase letter'
      if (!hasNumbers) errors.password = 'Must contain number'
    }

    return errors
  },

  async (formData) => {
    // Second validator: check age requirements
    const errors: Record<string, string> = {}

    if (formData.age) {
      const age = Number(formData.age)
      if (age < 13) {
        errors.age = 'You must be at least 13 years old'
      } else if (age > 120) {
        errors.age = 'Please enter a valid age'
      }
    } else {
      errors.age = 'Please enter an age'
    }

    return errors
  }
]

const App = () => {
  return (
    <FormViewer
      view={muiView}
      formValidators={validators}
      getForm={() => JSON.stringify(formJson)}
    />
  )
}

Live example

live

function App() {
  const formJson = {
    "errorType": "MuiErrorWrapper",
    "tooltipType": "MuiTooltip",
    "form": {
      "key": "Screen",
      "type": "Screen",
      "children": [
        {
          "key": "username",
          "type": "MuiTextField",
          "props": {
            "label": {
              "value": "Username"
            }
          }
        },
        {
          "key": "password",
          "type": "MuiTextField",
          "props": {
            "label": {
              "value": "Password"
            },
            "type": {
              "value": "password"
            }
          }
        },
        {
          "key": "age",
          "type": "MuiTextField",
          "props": {
            "label": {
              "value": "Age"
            }
          }
        },
        {
          "key": "validate",
          "type": "MuiButton",
          "props": {
            "children": {
              "value": "Validate",
            }
          },
          "events": {
            "onClick": [
              {
                "name": "validate",
                "type": "common"
              }
            ]
          }
        }
      ]
    }
  }

  // Define external form validators
  const registrationValidators = [
    async (formData) => {
      const errors = {}

      if (!formData.username) {
        errors.username = 'Please provide the username'
      }

      // Check if username is already taken (simulate async check)
      if (formData.username === 'admin') {
        errors.username = 'Username "admin" is reserved'
      }

      if (!formData.password) {
        errors.password = 'Please provide the password'
      }

      // Validate password strength
      if (formData.password) {
        const hasUpperCase = /[A-Z]/.test(formData.password)
        const hasLowerCase = /[a-z]/.test(formData.password)
        const hasNumbers = /\d/.test(formData.password)

        if (!hasUpperCase) errors.password = 'Must contain uppercase letter'
        if (!hasLowerCase) errors.password = 'Must contain lowercase letter'
        if (!hasNumbers) errors.password = 'Must contain number'
      }

      return errors
    },

    async (formData) => {
      // Second validator: check age requirements
      const errors = {}

      if (formData.age) {
        const age = Number(formData.age)
        if (age < 13) {
          errors.age = 'You must be at least 13 years old'
        } else if (age > 120) {
          errors.age = 'Please enter a valid age'
        }
      } else {
        errors.age = 'Please enter an age'
      }

      return errors
    }
  ]

  return (
    <FormViewer
      view={muiView}
      formValidators={registrationValidators}
      getForm={() => JSON.stringify(formJson)}
    />
  )
}

Combining JSON Form Validator with External Validators

When both formValidator (in JSON) and formValidators (external) are provided, FormEngine Core runs all validators and combines their results:

// External validator
const externalValidator: FormValidator = async (formData) => {
  const errors: Record<string, string> = {}

  // Business rule: premium users must provide company name
  if (formData.accountType === 'premium' && !formData.companyName) {
    errors.companyName = 'Company name is required for premium accounts'
  }

  return errors
}

{
"formValidator": "  const errors = {};\n  if (!formData.email) {\n    errors.email = 'Email is
required';\n  }\n  if (!formData.password) {\n    errors.password = 'Password is required';\n  }\n
return errors;",
  "tooltipType": "MuiTooltip",
  "errorType": "MuiErrorWrapper",
  "form": {
    "key": "Screen",
    "type": "Screen"
  }
}

Form Validator Execution Order

When form validation is triggered (e.g., by the validate action), FormEngine Core executes validators in this order:

Field-level validators: Each field’s individual validators run
JSON formValidator: The validator defined in the JSON formValidator field runs
External formValidators: All validators in the formValidators array run

Errors from all sources are combined. If multiple validators return errors for the same field, the errors are concatenated (unless showAllValidationErrors is false, in which case only the first error is shown).

Live example

live

function App() {
  const formJson = {
    "formValidator": "  const errors = {};\n  if (!formData.email) {\n    errors.email = 'Email is required';\n  }\n  if (!formData.password) {\n    errors.password = 'Password is required';\n  }\n  return errors;",
    "tooltipType": "MuiTooltip",
    "errorType": "MuiErrorWrapper",
    "form": {
      "key": "Screen",
      "type": "Screen",
      "children": [
        {
          "key": "email",
          "type": "MuiTextField",
          "props": {
            "label": {
              "value": "Email"
            }
          }
        },
        {
          "key": "password",
          "type": "MuiTextField",
          "props": {
            "label": {
              "value": "Password"
            }
          }
        },
        {
          "key": "accountType",
          "type": "MuiSelect",
          "props": {
            "items": {
              "value": [
                {
                  "value": "free",
                  "label": "Free"
                },
                {
                  "value": "premium",
                  "label": "Premium"
                }
              ]
            },
            "label": {
              "value": "Account Type"
            }
          }
        },
        {
          "key": "companyName",
          "type": "MuiTextField",
          "props": {
            "label": {
              "value": "Company Name"
            }
          }
        },
        {
          "key": "validate",
          "type": "MuiButton",
          "props": {
            "children": {
              "value": "Validate"
            }
          },
          "events": {
            "onClick": [
              {
                "name": "validate",
                "type": "common"
              }
            ]
          }
        }
      ]
    }
  }

  // External validator
  const externalValidator = async (formData) => {
    const errors = {}

    // Business rule: premium users must provide company name
    if (formData.accountType === 'premium' && !formData.companyName) {
      errors.companyName = 'Company name is required for premium accounts'
    }

    return errors
  }

  const formValidators = [externalValidator]

  return (
    <FormViewer
      view={muiView}
      formValidators={formValidators}
      getForm={() => JSON.stringify(formJson)}
    />
  )
}

Error Handling in Form Validators

Form validators should handle errors gracefully:

// Good: Returns error object with specific messages
async function validateForm(formData) {
  try {
    const errors = {}

    // Your validation logic
    if (!formData.email) {
      errors.email = 'Email is required'
    }

    // Async validation example
    if (formData.email) {
      const isAvailable = await checkEmailAvailability(formData.email)
      if (!isAvailable) {
        errors.email = 'Email is already registered'
      }

      return Object.keys(errors).length > 0 ? errors : undefined;
    }
  } catch (error) {
    // Log error but don't crash the form
    console.error('Form validation error:', error);
  }
}

Best Practices for Form Validators

Keep validators focused: Each validator should check a specific aspect of the form
Use async validators for server-side checks: Email availability, username uniqueness, etc.
Provide clear error messages: Tell users exactly what needs to be fixed
Validate early: Use field-level validation for simple checks, form-level for complex relationships
Test edge cases: Empty forms, partial data, invalid types
Performance considerations: Avoid expensive operations in synchronous validators

Best Practices

1. Provide Clear Error Messages

Do: “Password must be at least 8 characters and include a number”
Don’t: “Invalid password”

2. Validate Early and Often

Use autoValidate: true (default) for real-time feedback

3. Use Appropriate Validator Types

Use built-in validators when possible (more efficient)
Use code validators for complex business logic
Use custom validators for reusable validation patterns

4. Test Edge Cases

Empty values
Null/undefined values
Extremely long values
Special characters
Boundary conditions (min/max values)

5. Performance Considerations

Avoid complex calculations in validateWhen conditions

Troubleshooting

Validation Not Working

Check schema type: Ensure schema.type matches the field’s data type
Verify validator keys: Check for typos in validator key names
Check autoValidate: If autoValidate: false, validation only triggers manually

Custom Validators Not Recognized

Verify registration: Ensure custom validators are registered before form rendering
Check type: Custom validators need "type": "custom" in JSON
Verify parameters: Ensure required parameters are provided

Conditional Validation Not Executing

Check validateWhen syntax: Ensure JavaScript expression is valid
Verify field references: Use form.data['fieldName'] to reference other fields
Test condition separately: Log the condition result to debug

Error Messages Not Displaying

Check error wrapper: Ensure ErrorWrapper components are properly configured
Verify CSS: Custom error styles might conflict with default styles
Check form configuration: showAllValidationErrors might affect display

For more information:

Next steps

Form Submission — Handle form submission and process submitted data
Conditional Logic — Apply validation rules only when certain conditions are met

Last modified on April 16, 2026

FormEngine JSON Schema - Form Configuration Reference FormEngine Core Features Overview

​What is Validation?

​How Validation Works

​Validation Flow

​Field Validation

​Adding Validation to Fields

​JSON Configuration

​Live example

​Built-in Validators Based on Zod

​String Validators

​Number Validators

​Date Validators

​Array Validators

​Boolean Validators

​Time Validators

​Form Validation

​Form-Level Validation

​Live example

​Conditional Validation

​Using validateWhen Property

​Live example

​Complex Conditional Validation

​Live example

​Code Validation

​Code Validation Parameters

​Basic Code Validation

​Live example

​Cross-Field Validation with Code

​Live example

​Custom Validation

​Registering Custom Validators

​Using Custom Validators

​Live example

​Custom Validator with Parameters

​Live example

​Automatic Validation

​How Automatic Validation Works

​Disabling Automatic Validation

​Validation Error Display

​Default Error Display

​Custom Error Display

​Showing All Validation Errors

​Live example

​Advanced Form Validation

​Form Validator in JSON (formValidator)

​Basic Example

​Live example

​Form Validator Function Signature

​External Form Validators via FormViewer (formValidators)

​Registering External Form Validators

Live example

​Combining JSON Form Validator with External Validators

​Form Validator Execution Order

​Live example

​Error Handling in Form Validators

​Best Practices for Form Validators

​Best Practices

​1. Provide Clear Error Messages

​2. Validate Early and Often

​3. Use Appropriate Validator Types

​4. Test Edge Cases

​5. Performance Considerations

​Troubleshooting

​Validation Not Working

​Custom Validators Not Recognized

​Conditional Validation Not Executing

​Error Messages Not Displaying

​Next steps

What is Validation?

How Validation Works

Validation Flow

Field Validation

Adding Validation to Fields

JSON Configuration

Live example

Built-in Validators Based on Zod

String Validators

Number Validators

Date Validators

Array Validators

Boolean Validators

Time Validators

Form Validation

Form-Level Validation

Live example

Conditional Validation

Using validateWhen Property

Live example

Complex Conditional Validation

Live example

Code Validation

Code Validation Parameters

Basic Code Validation

Live example

Cross-Field Validation with Code

Live example

Custom Validation

Registering Custom Validators

Using Custom Validators

Live example

Custom Validator with Parameters

Live example

Automatic Validation

How Automatic Validation Works

Disabling Automatic Validation

Validation Error Display

Default Error Display

Custom Error Display

Showing All Validation Errors

Live example

Advanced Form Validation

Form Validator in JSON (formValidator)

Basic Example

Live example

Form Validator Function Signature

External Form Validators via FormViewer (formValidators)

Registering External Form Validators

Combining JSON Form Validator with External Validators

Form Validator Execution Order

Live example

Error Handling in Form Validators

Best Practices for Form Validators

Best Practices

1. Provide Clear Error Messages

2. Validate Early and Often

3. Use Appropriate Validator Types

4. Test Edge Cases

5. Performance Considerations

Troubleshooting

Validation Not Working

Custom Validators Not Recognized

Conditional Validation Not Executing

Error Messages Not Displaying

Next steps
